ASUS RS720A-E11-RS24U
AMD EPYC™ 7003 2U dual-socket server that supports up to 32 DIMM, four dual-slot GPUs (GPU SKU), 24 NVMe, nine PCIe 4.0 slots, OCP 3.0, M.2 and ASUS ASMB10-iKVM
Four Dual-slot GPUs Support
ASUS RS720A-E11 servers feature a powerful GPU* architecture that supports up to four dual-slot GPUs* such as NVIDIA A100 in one 2U system to enable easy scale-up in order to meet the demands of AI and high-performance computing (HPC), and to securely run workloads in virtualized environments.
KEY FEATURES
- Powered by AMD EPYC 7003 processor with 64 cores, 128 threads and support for a maximum TDP of up to 280 watts per socket
- GPU-optimized design allows four dual-slot GPUs for AI workloads (GPU SKU)
- Up to 24 all-flash NVMe drives on front panel to enable extensive storage and high-throughput performance
- Up to nine PCIe® 4.0 slots to enable higher bandwidth and improved data-transfer rates
- Flexible onboard LAN-module design to enable four 1 Gb LAN or two 10 Gb LAN options
- Flexible air and liquid cooling solution to achieve lower power-usage effectiveness (PUE) and optimized TCO for data centers
- Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller
- Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
- High power efficiency with redundant 2400W 80 Plus Titanium power supplies
Specifications
Processor / System Bus
2 x Socket SP3 (LGA 4094)
AMD EPYC™ 7003 Series
AMD EPYC™ 7002 Series
Max TDP : 280W
Memory
Total Slots :
32 (8-channel per CPU, 16 DIMM per CPU) Option 1
Capacity :
Maximum up to 4096GB per socket
Memory Type :
Dual Channel DDR4 3200/2933 RDIMM
Dual Channel 3200/2933 LRDIMM
Dual Channel 3200/2933 LR-DIMM 3DS non ECC
Memory Size :
64GB, 32GB, 16GB RDIMM
128GB, 64GB LRDIMM
256GB, 128GB, 64GB LR-DIMM 3DS
Expansion Slots
Up to 9 x Expansion slots
2 x PCIe Gen4 x8 or 1 x PCIe Gen4 x16, FHFL (CPU1 x1)
1 x PCIe Gen4 x8, FHFL (CPU1 x1)
1 x PCIe Gen4 x16, FHFL or OCP 3.0 NIC socket (CPU1 x1)
4 x PCIe Gen4 x8 or 2 x PCIe Gen4 x16, FHFL (CPU2 x2)
1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2 x1)
*Installing GPU cards will occupied expansion slots.
Storage
Storage Controller :
8 x SATA3 6Gb/s ports (SATA 6Gb/s & PCIe® Gen4 x4 link)
2 x M.2 connector(2242/2260/2280/22110) both SATA & PCIe mode
SAS Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card(Optional)
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card(Optional)
Broadcom MegaRAID 9560-16i (Optional)
Support 24 NVMe SKU:
24 x 2.5″ hot-swap drive bays (16xNVMe + 8NVMe/SATA/SAS*)
2 x M.2 (support SATA/PCIe M.2) (up to 22110) (CPU2)
Support 12 NVMe SKU:
24 x 2.5″ hot-swap drive bays (12xNVMe + 8SATA/SAS*)
2 x M.2 (support SATA/PCIe M.2) (up to 22110) (CPU2)
2 x 2.5″ hot-swap drive bays (2x SATA/NVMe)(optional rear bays)
*must with PIKE/RAID card
Front I/O Ports
2 x USB 3.2 Gen1 ports
Rear I/O Ports
2 x USB 3.2 Gen1 ports
1 x VGA port
1 x RJ-45 Mgmt LAN port
1 x OCP3.0 port (Please remember to insert OCP3.0 Board)
Power Supply
1+1 Redundant 1600W 80 PLUS Platinum Power Supply
Rating:
100-127/200-240Vac,13A/9.5A (x2) ,50/60Hz Class I (240Vdc, 4.6A Only for China)
200-240Vac,10A (x2) ,50/60Hz Class I (240Vdc, 4.6A Only for China；100-127Vac, 12A only for NA)
1+1 Redundant 2400W 80 PLUS Titanium Power Supply
*2400W RPSU is required while choosing GPU SKU
